Switching power supply IP67 12V, 5A 60Watt (LPV-60-12)

SKU: 10048
  • GTIN: 4021087006873
  • HAN: LPV-60-12
  • 12 V / 5 A / 60 W, fixed output voltage, tolerance ±5 %
  • Fully encapsulated to IP67, indoor and outdoor without direct sunlight
  • Plastic case, protection class II, connection leads, input 90–264 V AC
21,90 €
incl. 19% VAT , plus shipping costs
  • Available immediately
  • Delivery time: 2 - 7 days  (DE - int. shipments may differ)
  • Available immediately
  • Delivery time: 2 - 7 days  (DE - int. shipments may differ)
Description

Technical details:

  • Input voltage: 90–264 V AC
  • Output voltage: 12 V (±5 %)
  • Output current: 5 A
  • Output power: 60 W
  • Protection: IP67, fully encapsulated
  • Plastic case, protection class II
  • Connection via leads
  • Manufacturer: MEAN WELL, model LPV-60-12

Suitable for single 12 V pixel strings and short 12 V pixel strips up to 60 W total power. For indoor and outdoor use without direct sunlight.

Characteristics
Item information Value
Protection class: II (no earth conductor)
Output power: 60 W
Ambient operating temperature: −30 to +70 °C (derating per datasheet)
Output voltage: 12 V DC (fixed)
Enclosure: Plastic, fully encapsulated
Input voltage: 90–264 V AC / 127–370 V DC, 47–63 Hz
Output current: 0–5 A
Mounting: Screw mounting via mounting tabs
Dimensions: 162.5 × 42.5 × 32 mm
Weight: 0.40 kg
Ripple & noise: max. 120 mVp-p
Efficiency: typ. 83 %
Protection functions: Short circuit, overload, overvoltage
Cooling: Free-air convection (no fan)
Protection rating: IP67
Connection: Input and output connection leads
Power class: max. 100 W
Shipping weight: 0,50 kg
