Switching power supply IP67 5V, 6A 30Watt (LPV-35-5)

SKU: 10050
  • GTIN: 4021087006880
  • HAN: LPV-35-5
  • 5 V / 6 A / 30 W, fixed output voltage, tolerance ±6 %
  • Fully encapsulated to IP67, indoor and outdoor without direct sunlight
  • Plastic case, protection class II, connection leads, input 90–264 V AC
19,90 €
incl. 19% VAT , plus shipping costs
  • Available immediately
  • Delivery time: 2 - 7 days  (DE - int. shipments may differ)
  • Available immediately
  • Delivery time: 2 - 7 days  (DE - int. shipments may differ)
Description

Technical details:

  • Input voltage: 90–264 V AC
  • Output voltage: 5 V (±6 %)
  • Output current: 6 A
  • Output power: 30 W
  • Protection: IP67, fully encapsulated
  • Plastic case, protection class II
  • Connection via leads
  • Manufacturer: MEAN WELL, model LPV-35-5

Suitable for single 5 V pixel strings and short 5 V pixel strips up to 30 W total power. For indoor and outdoor use without direct sunlight.

Characteristics
Item information Value
Protection class: II (no earth conductor)
Output power: 30 W
Ambient operating temperature: −30 to +65 °C (derating per datasheet)
Output voltage: 5 V DC (fixed)
Enclosure: Plastic, fully encapsulated
Input voltage: 90–264 V AC / 127–370 V DC, 47–63 Hz
Output current: 0–6 A (Class 2 to UL 1310 up to 5 A)
Mounting: Screw mounting via mounting tabs
Dimensions: 148 × 40 × 30 mm
Weight: 0.31 kg
Ripple & noise: max. 80 mVp-p
Efficiency: typ. 77 %
Protection functions: Short circuit, overload, overvoltage
Cooling: Free-air convection (no fan)
Protection rating: IP67
Connection: Input and output connection leads
Power class: max. 100 W
Shipping weight: 0,40 kg
